EVO X Line ger den senaste tekniken i en kompakt design med komponenter av högsta kvalitet. Från en banbrytande teknik tog SounDigital till billjudförstärkare något som inte hade utforskats ännu. Den termiska kopplingen genom RTGP-system. Det exklusiva RTGP-systemet (Thermal Recovery for power generation) garanterar SoundDigital-produkter både högre termisk effektivitet och robusthet med högre stabilitet.
Compatible with SD-RLC Remote level control.
Power @ 12.6V @ 4Ω: 1 X 8712 WRMS
Power @ 12.6V @ 2Ω: 1 X 13200 WRMS
Power @ 12.6V @ 1Ω: 1 X 20000 WRMS
Power @ 14.4V @ 4Ω: 1 X 9714 WRMS
Power @ 14.4V @ 2Ω: 1 X 14718 WRMS
Power @ 14.4V @ 1Ω: 1 X 22300 WRMS
Operating Voltage: 8V – 16V
Current Draw (Music): 980 A
Current Draw (Max): 1960 A
Recommended Fuse (Music): 1200 A
Total Efficiency: 81%
Damping Factor: 200
Frequency Response (-3dB): 5Hz – 500Hz
SNR: 76dB
Crossover HPF: 5Hz – 30Hz
Crossover LPF: 50Hz – 500Hz
THD + N (10% Rated Power): 0.2%
Product Dimensions: 34 x 8.8 x 2.8 in
Do not run your amp under rated impedance!
Compatible with SD-RLC Remote level control.
Power @ 12.6V @ 4Ω: 1 X 8712 WRMS
Power @ 12.6V @ 2Ω: 1 X 13200 WRMS
Power @ 12.6V @ 1Ω: 1 X 20000 WRMS
Power @ 14.4V @ 4Ω: 1 X 9714 WRMS
Power @ 14.4V @ 2Ω: 1 X 14718 WRMS
Power @ 14.4V @ 1Ω: 1 X 22300 WRMS
Operating Voltage: 8V – 16V
Current Draw (Music): 980 A
Current Draw (Max): 1960 A
Recommended Fuse (Music): 1200 A
Total Efficiency: 81%
Damping Factor: 200
Frequency Response (-3dB): 5Hz – 500Hz
SNR: 76dB
Crossover HPF: 5Hz – 30Hz
Crossover LPF: 50Hz – 500Hz
THD + N (10% Rated Power): 0.2%
Product Dimensions: 34 x 8.8 x 2.8 in
Do not run your amp under rated impedance!
Tekniska data
| Antal kanaler | 1 |
| Förstärkarklass | D |
| Effekt i 1 ohm RMS | 12.6/14.4V 20000/22300W |
| Effekt i 2 ohm RMS | 12.6/14.4V 13200/14718W |
| Effekt i 4 ohm RMS | 12.6/14.4V 8712/9714W |
| Frekvensområde | 5Hz – 500Hz |
| Högpassfilter | ja |
| Lågpassfilter | ja |
| Driftspänning | 8-16V |
| Dämpfaktor | 200 |
| Dimensioner | 34 x 8.8 x 2.8 in |
