EVO X Line ger den senaste tekniken i en kompakt design med komponenter av högsta kvalitet. Från en banbrytande teknik tog SounDigital till billjudförstärkare något som inte hade utforskats ännu. Den termiska kopplingen genom RTGP-system. Det exklusiva RTGP-systemet (Thermal Recovery for power generation) garanterar SoundDigital-produkter både högre termisk effektivitet och robusthet med högre stabilitet.
Compatible with SD-RLC Remote level control.
Power @ 12.6V @ 4Ω: 1 X 3485 WRMS
Power @ 12.6V @ 2Ω: 1 X 5280 WRMS
Power @ 12.6V @ 1Ω: 1 X 8000 WRMS
Power @ 14.4V @ 4Ω: 1 X 3886 WRMS
Power @ 14.4V @ 2Ω: 1 X 5887 WRMS
Power @ 14.4V @ 1Ω: 1 X 8920 WRMS
Operating Voltage: 8V – 16V
Current Draw (Music): 402 A
Current Draw (Max): 804 A
Recommended Fuse (Music): 500 A
Total Efficiency: 79%
Damping Factor: 1000
Frequency Response (-3dB): 5Hz – 500Hz
SNR: 82dB
Crossover HPF: 5Hz – 30Hz
Crossover LPF: 50Hz – 500Hz
THD + N (10% Rated Power): 0.08%
Product Dimensions: 13.9 x 8.8 x 2.8 in
Product Dimensions: 35.4 x 22.5 x 7.1 cm
Do not run your amp under rated impedance!
Compatible with SD-RLC Remote level control.
Power @ 12.6V @ 4Ω: 1 X 3485 WRMS
Power @ 12.6V @ 2Ω: 1 X 5280 WRMS
Power @ 12.6V @ 1Ω: 1 X 8000 WRMS
Power @ 14.4V @ 4Ω: 1 X 3886 WRMS
Power @ 14.4V @ 2Ω: 1 X 5887 WRMS
Power @ 14.4V @ 1Ω: 1 X 8920 WRMS
Operating Voltage: 8V – 16V
Current Draw (Music): 402 A
Current Draw (Max): 804 A
Recommended Fuse (Music): 500 A
Total Efficiency: 79%
Damping Factor: 1000
Frequency Response (-3dB): 5Hz – 500Hz
SNR: 82dB
Crossover HPF: 5Hz – 30Hz
Crossover LPF: 50Hz – 500Hz
THD + N (10% Rated Power): 0.08%
Product Dimensions: 13.9 x 8.8 x 2.8 in
Product Dimensions: 35.4 x 22.5 x 7.1 cm
Do not run your amp under rated impedance!
Tekniska data
| Antal kanaler | 1 |
| Förstärkarklass | D |
| Effekt i 1 ohm RMS | 8000W |
| Effekt i 2 ohm RMS | 5280W |
| Effekt i 4 ohm RMS | 3485W |
| Effekt i 1 ohm RMS 14.4V | 8920W |
| Effekt i 2 ohm RMS 14.4V | 5887W |
| Effekt i 4 ohm RMS 14.4V | 3887W |
| Frekvensområde | 5Hz – 500Hz |
| Högpassfilter | Ja |
| Lågpassfilter | Ja |
| Driftspänning | 8-16V |
| Dämpfaktor | 1000 |
| Dimensioner | 35.4 x 22.5 x 7.1 cm |
